2.4GHz 9dBi Indoor Desktop Omni-directional Antenna with magnetic base, lock swivel design

Availability: In stock

Model number: E318

Gain

Part no.

Connector (cable)

9dBi

M24-9-SR-MB-L

RP-SMA (M)

7dBi

M24-7-SR-MB-L

RP-SMA (M)

Inquiry
Quantity

Electrical:

  • Type: Dipole antenna
  • Frequency: 2.4~2.5GHz
  • VSWR: ≤2.0
  • Impedance: 50ohms
  • Gain: 9dBi
  • Radiation: omni
  • Electrical Wave: 1/4
  • Polarization: Vertical
  • Max Power: 1W

Mechanical:

  • Antenna length: 196.6mm (SMA)
  • Magnetic base: OD60x H43 (mm)
  • Magnetic cable: RG174 1.5meter x RP-SMA male
  • Operating temp.: -30 to +80 degree
  • Storage temp.: -30 to +85 degree
  • Materials: ABS (Antenna Cover)
  • Color: Black

Mounting:

  • Magnetic Base with RG174 1.5m cable + RP-SMA(M)

Made in Taiwan

OEM and ODM orders are welcome

Compliant with RoHS Directive
