5-in-1 Multi-band Vehicle Antenna (LTE Cellular*2, WiFi*2, GPS*1). Screw or Magnet mount

5-in-1 Multi-band Vehicle Antenna (LTE Cellular*2, WiFi*2, GPS*1). Screw or Magnet mount

Availability： In stock

Model number： CAR-GPS-G12F

Part no.

Size

Frequency

GPS-G12F-SW

86x140mm

LTE Cellular*2, WiFi*2, GPS*1

GPS-G12F-MA

98x140mm

LTE Cellular*2, WiFi*2, GPS*1

Inquiry
Quantity
    Share

    Electrical:

    • Type: Screw Mount【Car Roof】and Magnetic Mount
    • Frequency:
      2 x cellular (694-960/1710-2170MHz)
      2 x Wi-Fi (2.4-2.5/5.15-5.85GHz)
      1 x GPS (1575.42MHz)
    • VSWR: ≤2.0
    • Impedance: 50ohm
    • Gain: 2.5dBi for cellular, 27dB for GPS
    • Radiation: Omni
    • Electrical wave: 1/2
    • Polarization: Vertical
    • Max Power: 50W

    Mechanical:

    • Antenna height: 86x140mm (SW),  98x140mm (MA)
    • Operating temp.: -30 to +85 degree
    • Storage temp.: -35 to +85 degree

    Mounting

    • Screw Mount or Magnetic Mount

    Pigtail Cable and connector:

    • Cable: CFD200 low loss 5M *4 + RG-174A/U 5M *1   (customized cable length)
    • Connector: SMA/M *3 + SMA/M RP *2
    • Or cutting open end

    Made in Taiwan

    OEM and ODM orders are welcome

    Compliant with RoHS Directive
