Electrical:

• Frequency Range: 1710-2700MHz High Band
• V.S.W.R (MAX):  1.5:1
• Radiation: Directional
• Polarization: Vertical
• Gain 8dBi
• Input Impedance: 50ohm
• 3dB Beamwidth: H:65° E:55°
• F/B Ratio: ≥15dB
• Max. Power: 50W
• Lightning Protection: DC Ground
• Connector: N Female
• Pigtail Length 30cm

Mechanical:

• Size: 14 x 12 x 3.9 cm (HxWxD)
• Antenna Weight:  0.2kg
• Reflector Material:  Aluminum
• Radome Color: White
• Operating Temp.: -40°C~+65°C
• Relative Humidity: Up to 100%
• Application: Indoor

Accessory:

• Bracket 1 set
• Mounting screw 4 sets
• Optional Accessory:
  AD-N1F0-06 : N(M) – F(F) for RG 6/u cable

• AD-N1F0-11 : N(M) – F(F) for RG 11/u cable

Made in Taiwan

OEM and ODM orders are welcome

Compliant with RoHS Directive
