4dBi 615~2700MHz 4G LTE Boardband Antenna with N Female. IP67 / Anti-UV for indoor/outdoor

Availability: In stock

Model number: W51NF

Part no.

N Female (straight)

2.4GHz

M51-NF

2.4/5GHz

F51-NF

4G LTE

W51-NF

Inquiry
Quantity

Electrical:

  • Type: Dipole antenna
  • Frequency: 615-960 / 1710-2170 / 2300-2700MHz
  • VSWR: ≤2.0
  • Impedance: 50ohms
  • Gain: 1-4dBi
  • Radiation: omni
  • Electrical Wave: 1/4
  • Polarization: Vertical
  • Max Power: 1W
  • Waterproof : IP67-rating

Mechanical:

  • Antenna length: 182.3mm
  • Operating temp.: -30 to +70 degree
  • Storage temp.: -30 to +80 degree
  • Materials: ABS/PC (Anti-UV)
  • Color: Pure White and Black

Mounting:

  • N Female



Made in Taiwan

OEM and ODM orders are welcome

Compliant with RoHS Directive
